Maclean MCE623 B PIR Motion Sensor 12-24V DC, 180°, 12m, IP44, Black
Price: 10.00 €
| Products ID: | 173717 |
|---|---|
| Manufactured by: | Maclean |
| Availablity: | Ready to Order |
| Delivery Time | 5-15 business days |
| EAN: | 5902211145929 |
Delivery options to:
LatviaOffice pickup
Free
Estimated: 25.09.–09.10.
Parcel-machine delivery
from 1.90 €
Estimated: 29.09.–13.10.
Courier delivery
4.90 €
Estimated: 29.09.–13.10.
The Maclean MCE623 B is an infrared PIR motion sensor designed for automatic control of low-voltage 12–24 V DC lighting systems.
Key Features
- Detection area: 180° detection angle and up to 12 m range with an adjustable sensor head.
- IP44 protection: splash-proof enclosure resistant to solid objects larger than 1 mm.
- Customizable settings: adjustable time delay from 10 seconds to 15 minutes and twilight threshold adjustment.
- Electrical capacity: maximum current of 5 A with a maximum load of 60/120 W at 12–24 V DC.
- Mounting: designed for wall installation at a height of 1.8 to 2.5 m.
| Manufacturer | Maclean |
|---|---|
| Model | MCE623 B |
| Color | Black |
| Voltage | 12–24 V DC |
| Detection technology | PIR |
| Detection angle | 180° |
| Detection range | Up to 12 m |
| Max. load | 60/120 W |
| Max. current | 5 A |
| Protection rating | IP44 |
| Time delay adjustment | 10 s – 15 min |
| Installation height | 1.8–2.5 m |
What is the detection range and angle of this sensor?
The sensor detects movement within a 180° angle at a distance of up to 12 meters.
What supply voltage does the sensor require?
It operates on low-voltage 12–24 V DC power.
What is the recommended installation height?
The sensor is designed for wall mounting at a height of 1.8 to 2.5 meters.
