Electronic Irrigation Valve RainPoint BIV025ESC-DC 1" DC Latch IP68

20.80 € 26.10 € You save 5.30 € incl. VAT
In supplier warehouse · 151 pcs. Delivery Time: 4–10 business days

In your cart: 0

Delivery options to:

Latvia
Store pickup Estimated: 26.11.–04.12.
Free
Parcel locker delivery Estimated: 30.11.–08.12.
from 1.90 €
Courier delivery Estimated: 30.11.–08.12.
from 4.90 €

The RainPoint BIV025ESC-DC electronic solenoid valve with 1" thread is designed for automated water flow control in garden irrigation systems.

Key Features

  • Operates at 9–24 V DC using a DC Latch pulse coil for low energy consumption.
  • Standard 1" BSP connections provide compatibility with irrigation controllers and fittings.
  • Supports an operating pressure range of 0.2–10 bar and operating temperatures up to 60°C.
  • Sealed construction with IP68 ingress protection for operation in wet outdoor environments.

ManufacturerRainPoint
ModelBIV025ESC-DC
Connection diameter1”
Operating voltage9–24 V DC (Latch)
Control typePulse (DC Latch)
Pulse duration≥200 ms
Minimum capacitance4700 µF
Operating pressure0.2–10 bar
Operating temperatureup to 60°C
Protection ratingIP68
EAN5905156102774
What connection thread does this valve use?

The valve uses standard 1" BSP threaded connections.

What power supply is required to trigger the valve?

It operates on 9–24 V DC latch pulse control with a pulse duration of 200 ms or greater.

What is the supported operating pressure range?

The valve operates within a pressure range of 0.2 to 10 bar.
